Monel Sheet / Plate / Coil
Product Grades:
- Monel 400 (UNS N04400 / W.Nr. 2.4360)
- Monel K500 (UNS N05500 / W.Nr. 2.4375)
- Monel R-405 (UNS N04405 / W.Nr. 2.4361)
- Monel 401 (UNS N04401)
- Monel 404 (UNS N04404)
- Monel 502 (UNS N05502)
Implementation Standards: ASTM B127 for plates, sheets, and strips; ASME SB127.
Certification: ISO 9001:2015.
Features:
- Superior Corrosion Resistance: Excellent performance in both reducing and oxidizing environments, including marine and acidic conditions.
- High Strength and Durability: Retains high strength at elevated temperatures, suitable for high-stress applications.
- Excellent Resistance to Pitting, Crevice Corrosion, and Stress Corrosion Cracking: Ensures durability in harsh environments.
Applications: Ideal for chemical processing, marine applications, oil and gas production, and power generation.
MOQ: 500 KG.
Payment Methods: T/T, L/C.
Price: Negotiable.
Monel Sheet / Plate / Coil Supplier
Monel Sheets, Monel Plates, ASME SB127 Monel Plates, Monel Alloy Coils, Monel Slitting Coils, Monel Perforated Coils Supplier in China.
Monel Cold Rolled Plates, ASTM B127 Monel Shim Sheets, Monel Sheets, Monel Alloy Plates Exporter, Monel Sheets Dealer Worldwide.
Huaxiao Alloy, a leading supplier and exporter in China, specializes in providing a comprehensive range of Monel Alloy Sheets, Plates, and Coils to customers globally. Our high-quality Monel products are known for their exceptional corrosion resistance and superior performance in extreme environments. Manufactured at state-of-the-art facilities, our products undergo strict quality checks to ensure they meet the highest international standards, including ASTM, ASME, and DIN.
We offer Monel Alloy Sheets, Plates, and Coils in a wide variety of grades, sizes, and specifications to cater to diverse industrial needs. We also provide customization services to meet specific client requirements.
Specifications for Monel Sheet / Plate / Coil
| Category | Thickness Range | Width Range | Length Range | Standard Specifications |
|---|---|---|---|---|
| Monel Sheets | 0.1 mm – 6 mm | 1000 mm – 2000 mm | 2000 mm – 6000 mm | ASTM B127, ASME SB127 |
| Monel Plates | 6 mm – 100 mm | 1000 mm – 2500 mm | 2000 mm – 8000 mm | ASTM B127, ASME SB127 |
| Monel Coils | 0.1 mm – 6 mm | 1000 mm – 2000 mm | Coil Lengths (as required) | ASTM B127, ASME SB127 |
- Standards: ASTM B127, ASME SB127
- Sizes:
- Width: 1000mm, 1220mm, 1250mm, 1500mm, 2000mm
- Length: 2000mm, 2440mm, 3000mm, 6000mm, or as per customer requirements
- Thickness Range: 0.1mm to 100mm
- Forms: Coils, Plates, Sheets, Shim Sheets, Foils, Circles, Flanges, and Rolls
- Surface Finishes: 2B, BA, No.4, Mirror, HL (Hairline), Satin, CR (Cold Rolled), HR (Hot Rolled)
- Hardness Levels: Soft, Half Hard, Quarter Hard, Full Hard, Spring Hard
Available Monel Grades
Available Monel Grades
We supply the following grades of Monel alloy sheets, plates, and coils:
- Monel 400 (UNS N04400 / W.Nr. 2.4360): Known for its high strength and excellent corrosion resistance in a range of acidic and alkaline environments.
- Monel K500 (UNS N05500 / W.Nr. 2.4375): Offers more strength and hardness than Monel 400 due to added aluminum and titanium, excellent resistance to corrosion in marine environments.
- Monel R-405 (UNS N04405 / W.Nr. 2.4361): Contains a small amount of sulfur, improving the machinability over Monel 400, suitable for fasteners and valve parts.
- Monel 401 (UNS N04401): Specially formulated for electrical and electronic applications, offers low electrical resistivity.
- Monel 404 (UNS N04404): Optimal for applications requiring low magnetic permeability and exceptional brazing characteristics.
- Monel 502 (UNS N05502): Exhibits corrosion resistance and high strength, similar to Monel K500, but with different mechanical properties due to variations in its elemental composition.
Key Features of Monel Sheet / Plate / Coil
Monel sheet, plate, and coil share a set of remarkable features that make them highly sought after for various industrial applications. Here are the key features of these Monel products:
Exceptional Corrosion Resistance: Monel sheet, plate, and coil are renowned for their excellent resistance to a wide range of corrosive environments, including seawater, chlorides, sulfur compounds, and acidic substances. This property makes them ideal for use in marine applications, chemical processing, and anywhere corrosion is a concern.
High Strength and Durability: Monel alloys offer a high strength-to-weight ratio, which is essential in applications that demand durability without the penalty of increased weight. This strength is maintained even at high temperatures, making Monel suitable for demanding operational conditions.
Thermal Stability: Monel maintains its mechanical properties over a wide range of temperatures, which is critical for applications subject to thermal cycling or extreme heat.
Excellent Weldability and Fabricability: Despite their strength, Monel alloys are relatively easy to fabricate and can be welded using conventional welding techniques. This ease of fabrication allows for the manufacturing of complex and intricate designs without compromising the integrity of the material.
Good Thermal Conductivity: Monel’s good thermal conductivity makes it suitable for heat exchanger plates, cooling systems, and other applications where efficient heat transfer is required.
Low Coefficient of Thermal Expansion: The low expansion rate of Monel under heat helps maintain structural integrity and dimensional stability, crucial in high-precision applications such as aerospace and scientific instruments.
Versatility: Monel sheet, plate, and coil are versatile in their applications, capable of being used in anything from basic structural components to critical, high-performance parts in aerospace and marine engineering.
Long Service Life: The durability and corrosion resistance of Monel contribute to a longer service life of products made from these materials, reducing the need for frequent replacement and maintenance.
Applications of Monel Sheet / Plate / Coil
Chemical Processing: Monel’s superb resistance to acids and other corrosive substances makes it an excellent material for use in the manufacture of reactors, vessels, pumps, valves, and piping systems in the chemical processing industry.
Marine Applications: Due to its excellent resistance to seawater and rapid flowing brackish water, Monel is widely used in making marine hardware, shafts, and fixtures that are exposed to marine environments.
Oil and Gas Production: Monel sheet and coil are used in offshore oil rig applications, sour gas environments, and for the manufacturing of safety lifts and valves in oil and gas extraction processes.
Aerospace Industry: The high strength and thermal stability of Monel make it suitable for aerospace applications, including parts of jet engines and aerospace fasteners that require both high strength and corrosion resistance at elevated temperatures.
Power Generation: In power plants, Monel is used in steam turbine exhaust systems, boiler feed water heaters, and other high-temperature, high-corrosion environments.
Electronic Industries: Monel plate is used in the production of electronic components that require materials with a specific expansion rate under varying thermal conditions.
Desalination Plants: Monel is critical in desalination equipment due to its resistance to the corrosive effects of high-concentration saltwater, which makes it suitable for pumps, heat exchangers, and other components.
Architectural and Structural Applications: In the architectural field, Monel is used for roofing, gutters, and siding, offering both aesthetic appeal and long-term durability against environmental exposure.
Packaging & Delivery
Packaging Options:
- Bundles with plastic wrapping for weather protection.
- Wooden crates or pallets for safe transportation.
- Custom packaging available based on client requirements.
Delivery Time: 10-25 days or faster if stock is available.
Why Choose Huaxiao Alloy?
- Made in China: Leading supplier of Monel alloys with international market expertise.
- Wide Grade Selection: Comprehensive range of Monel grades with customizable size options to meet specific industry needs.
- Stringent Quality Control: Ensuring compliance with international standards for high-performance alloys.
- Global Export Network: Trusted by clients in Europe, the Americas, the Middle East, and Asia for reliable delivery of Monel products.
- Competitive Pricing: High-quality Monel Sheets, Plates, and Coils at reasonable rates.
Contact us today for more details or to request a quote for Monel Alloy Sheets, Plates, and Coils!
Get Quote Now for Monel Sheet / Plate / Coil
FAQs
Monel, particularly Monel 400, is covered under various ASTM standards depending on the form. For example, Monel 400 is specified as:
- Plate, sheet, and strip: ASTM B127
- Pipe and tube: ASTM B165 (seamless) and ASTM B725 (welded)
- Bar: ASTM B164 These standards ensure that materials meet specific mechanical and chemical properties, providing a guideline for manufacturers and users.
Monel plate is a thick, flat piece of Monel alloy, typically Monel 400 or Monel K-500, used in applications where high strength, corrosion resistance, and durability are required. It is widely used in chemical processing equipment, marine engineering, and hydrocarbon processing due to its excellent resistance to sea water and various chemical environments.
- Monel 400 is a nickel-copper alloy known for its high strength, corrosion resistance, and excellent mechanical properties across a wide range of temperatures.
- Monel 405 is a variation of Monel 400 with a slightly different chemical composition that includes a small amount of sulfur. This addition improves the alloy’s machinability without significantly impacting its corrosion resistance. It is specifically designed for high-speed machining processes.
Yes, Monel is spark resistant. This makes it suitable for applications in explosive or flammable environments where sparking could be hazardous, such as tools for the oil and gas industry.
Monel and stainless steel each have their advantages depending on the application. Monel offers superior corrosion resistance in environments like seawater, making it better for marine applications. Stainless steel, however, is generally less expensive and has a wider range of heat resistance, making it more suitable for high-temperature environments. The choice depends on specific application needs regarding environment, cost, and mechanical properties.
Monel is extensively used in:
- Marine engineering for seawater valves, pumps, and ship hulls
- Chemical processing equipment due to its corrosion resistance
- Aerospace applications for its strength and resistance to corrosive fluids
- Oil and gas production where sulfur compounds and hydrofluoric acid are present
- Cost: Monel is more expensive than stainless steel and other conventional materials due to its nickel content.
- Machinability: It is relatively difficult to machine compared to other materials, requiring specialized tools and techniques, which can increase manufacturing costs.
- Availability: Less commonly available in various forms compared to more widespread materials like stainless steel.
Yes, Monel is generally more expensive than many other metals due to its high nickel content, which is a costly raw material. Its specialized manufacturing and processing requirements also contribute to its higher price.
Monel and stainless steel can be differentiated through a few methods:
- Magnet Test: Monel is typically non-magnetic, while many common stainless steel grades are magnetic.
- Corrosion Test: Monel has superior resistance to corrosion, particularly to salt water, compared to stainless steel.
- Spark Test: When subjected to a grinder, Monel produces very few sparks with a dull finish, whereas stainless steel tends to generate more sparks with a brighter finish.
